Product Summary

The IRL1004PBF is a HEXFET Power MOSFET.

Parametrics

Absolute maximum ratings: (1)Continuous Drain Current, VGS @ 10V: 130 A; (2)Continuous Drain Current, VGS @ 10V: 92 A; (3)Pulsed Drain Current: 520 A; (4)Power Dissipation: 200 W; (5)Linear Derating Factor: 1.3 W/℃; (6)Gate-to-Source Voltage: ± 16 V; (7)Single Pulse Avalanche Energy: 700 mJ; (8)Avalanche Current: 78 A; (9)Repetitive Avalanche Energy: 20 mJ; (10)Peak Diode Recovery dv/dt: 5.0 V/ns; (11)Operating Junction and Storage Temperature Range: -55 to + 175℃; (12)Soldering Temperature, for 10 seconds: 300 (1.6mm from case) ℃; (13)Mounting torque, 6-32 or M3 srew: 10 lbf·in (1.1N·m).

Features

Features: (1)Logic-Level Gate Drive; (2)Advanced Process Technology; (3)Ultra Low On-Resistance; (4)Dynamic dv/dt Rating; (5)175℃ Operating Temperature; (6)Fast Switching; (7)Fully Avalanche Rated.

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
IRL1004PBF
IRL1004PBF
International Rectifier
MOSFET MOSFT 130A 66.7nC 6.5mOhm LogLvAB
Data Sheet
0-1: $2.18
1-25: $1.49
25-100: $1.11
100-250: $1.06
Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
IRL1004
IRL1004

MOSFET N-CH 40V 130A TO-220AB
Data Sheet
Negotiable
IRL1004L
IRL1004L

MOSFET N-CH 40V 130A TO-262
Data Sheet
Negotiable
IRL1004LPBF
IRL1004LPBF
International Rectifier
MOSFET MOSFT 40V 110A 6.5mOhm 66.7nC LogLv
Data Sheet
0-1: $1.92
1-25: $1.31
25-100: $0.98
100-250: $0.94
IRL1004PBF
IRL1004PBF
International Rectifier
MOSFET MOSFT 130A 66.7nC 6.5mOhm LogLvAB
Data Sheet
0-1: $2.18
1-25: $1.49
25-100: $1.11
100-250: $1.06
IRL1004S
IRL1004S

MOSFET N-CH 40V 130A D2PAK
Data Sheet
Negotiable
IRL1004SPBF
IRL1004SPBF
International Rectifier
MOSFET
Data Sheet
0-1: $1.90
1-25: $1.30
25-100: $1.06
100-250: $1.05
